AM COM-50

Specifications:

• Motor Size (HP): 15
• Displacement (CFM): 46.4
• Air Delivery (FAD): 41.3
• Max Psi: 150
• Tank Capacity (L): 500
• Dimensions CM LxWxH: 210 x 62 x 134
• Weight (Kg): 325

Tips:

Calculating CFM Requirements:
Find the required air flow (CFM) of your specific air tool. This information will be in your tools user guide.

• To find the minimum required CFM of the compressor you need multiply your tool’s required CFM by 1.5 Example: if you want to run a spray gun (4.5 CFM): 4.5 CFM x 1.5 = at least a 6.75 CFM compressor

If you’re going to be running multiple tools you’ll need to add together the individual CFM of each tool.

Calculating Tank Size:
To find the minimum tank size of the compressor you need to multiple your tool’s required CFM by 6.

• For example, if you run an impact wrench (6.75 SCFM): 6.75 CFM x 6 = at least a 40 litre compressor tank

The above Tip is based on a general rule of thumb overview.
